ProductOverview
G015455
1
2
3
4
5
6
Figure8
1.Hoodstrap
3.Cargobox5.Chargingreceptacle
2.Parkingbrake
4.Cargoboxreleaselever
6.Towingtongue
Controls
Figure9
1.Brakepedal5.Passengerhandhold
2.Parkingbrake/center
console
6.Operator'sManualtube
3.Steeringwheel
7.Acceleratorpedal
4.Cupholder
AcceleratorPedal
Theacceleratorpedal(Figure9)givestheoperatortheability
tovarytheengineandgroundspeedofthemachinewhen
thetransmissionisingear.Pressingthepedalincreasesthe
enginerpmandgroundspeed.Releasingthepedaldecreases
theenginespeedandgroundspeedofthemachine.
BrakePedal
Thebrakepedalisusedtoapplyservicebrakestostopor
slowthemachine(Figure9).
CAUTION
Brakescanbecomewornorcanbeincorrectly
adjustedresultinginpersonalinjury.
Ifthebrakepedaltravelstowithin25mm(1inch)
ofthemachineoorboard,thebrakesmustbe
adjustedorrepaired.
ParkingBrake
Theparkingbrakeisbetweentheseats(Figure9).Whenever
youshutoffthemachine,settheparkingbraketoprevent
themachinefromaccidentalmovement.Tosettheparking
brake,pullbackthelever.Toreleasetheparkingbrake,push
theleverforward.Ifthemachineisparkedonasteepgrade,
makesurethatyousettheparkingbrake.
On/OffSwitch
TheOn/Offswitch(Figure10),usedtoactivatetheelectrical
systemsofthemachine,has2positions:OnandOff.Rotate
15
