Figure35
1.Jamnut2.Tierod
8.Rotatebothtierodstomovethefrontofthetire
inwardoroutward.
9.Tightenthetierodjamnutswhentheadjustmentis
correct.
10.Ensurethatthereisfulltravelofthesteeringwheelin
bothdirections.
CheckingtheTransaxle-oil
Level
ServiceInterval:Every100hours
Oiltype:10W30(SAESJorhigher)
1.Parkthemachineonalevelsurface,settheparking
brake,andturnoffandremovethekey.
2.Removethellplugonthetransaxle(Figure36).
Note:Theoillevelshouldbeevenwiththebottom
ofthellplug.
Figure36
1.Fillplug2.Drainplug
3.Iftheoillevelislow,removethellplugandaddthe
speciedoiluntilitrunsoutofthehole(Figure36).
4.Replacethellplugandtorqueitto20to27N-m(15
to20ft-lb).
ChangingtheTransaxleOil
ServiceInterval:Every800hours
Oiltype:10W30(SAESJorhigher)
Oilcapacity:1.9L(2USqt)
1.Alignadrainpanunderthedrainplug(Figure36).
2.Removethellplugandtheseal(Figure36).
Note:Retainthellplugandsealforinstallationin
step6.
3.Removethedrainplugandtheseal,andallowtheoilto
draincompletely(Figure36).
Note:Retainthedrainplugandsealforinstallation
instep4.
4.Installthedrainplugandseal,andtorqueitto20to27
N-m(15to20ft-lb).
5.Fillthetransaxlewiththespeciedoiluntilitrunsout
ofthellhole.
6.Installthellplugandseal,andtorqueitto20to27
N-m(15to20ft-lb).
32
