12.Installthebeltcoversandtheboltsattachedto
them(Figure63).
g027730
Figure63
13.Installthesheet-metalguard;refertoRemoving
theSheet-MetalGuard(page35).
14.Tightenthebottomboltholdingthemower-deck
curtaintothemowerdeck;refertoReleasing
theMower-DeckCurtain(page34).
Replacingthe
Hydraulic-Pump-Drive
Belt
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch(PTO),andengagethe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removethemowerbelt;refertoReplacingthe
MowerBelt(page49).
4.Raisethemachineandsupportitwithjack
stands.
5.Removetheclutchstop(Figure64).
g036860
Figure64
1.Clutchstop
6.Removetheidlerspringfromthepost(Figure
65).
7.Removetheexistingbeltfromthe
hydraulic-pump-drivepulleysandthe
enginepulley.
8.Installthenewbeltaroundtheenginepulleyand
the2hydraulic-pumppulleys(Figure65).
g036859
Figure65
1.Idlerpulley4.Pump-drivebelt
2.Idler-springpost5.Righthydraulic-pump
pulley
3.Enginepulley
6.Lefthydraulic-pumppulley
9.Installtheclutchstop(Figure64).
10.Installthemowerbelt;refertoBeltMaintenance
(page49).
