Toro 22197 User Manual

thehandlelatchestothehandleintotheother
mountingholesinthelatches.
3.Slidethebagsupportrodthroughthesecondfrom
thetopmountingholesinthehandleandsecure
eachendwithacaplocknut(
Figure3).
4.Useacabletietosecurethecontrolcablestotheleft
handlebelowthebagsupportrod.
2
InstallingtheStarterRope
NoPartsRequired
Procedure
Pullthestarterropethroughtheropeguideonthe
handle(Figure4).
Figure4
1.Starterrope
2.Ropeguide
Note:Tomaketheropeeasiertoinstall,squeezethe
controlbaronthehandle.
3
InstallingtheFuelTank
Partsneededforthisprocedure:
2
Self-tappingscrew
1Fueltank
Procedure
1.Slidetheplasticclipsonthefrontofthefueltank
ontothefueltankmount(Figure5).
Figure5
1.Plasticclip(2)
2.Securethebottomofthefueltanktothefueltank
bracketbyinstallingtheself-tappingscrewsfrom
thebottom.Torquethescrewsto40to50in-lb
(4.5to5.6N-m).
8
