Toro 22303 User Manual

ProductOverview
G005939
1
2
3
4
5
20
17
6
18
7
8
13
14
15
12
11
21
9
18
16
4
14
19
10
22
Figure6
1.Mountplate7.Wheel
13.Controlpanel
19.Parkingbrakelever
2.Tiltcylinder
8.Liftcylinder14.Liftpoints20.Radiatorllcap
3.Auxiliaryhydrauliccouplers
9.Operatorplatform
(removablecounterweight
notshown)
15.Handle21.Thighsupport
4.Loaderarms
10.Rearaccesscover(open)
16.Battery22.Flowdividercontrol
5.Frontaccesscover11.Engine17.Indicatorlights
6.Fueltank
12.Airlter
18.Towvalves
Controls
Becomefamiliarwithallthecontrols(Figure7)before
youstarttheengineandoperatethetractionunit.
G006057
631524
78
Figure7
1.Tractioncontrollevers
5.Speedselectorlever
2.Attachmenttiltlever6.Throttlelever
3.Loaderarmlever7.Keyswitch
4.Auxiliaryhydraulicslever8.Hourmeter
KeySwitch
Thekeyswitch,usedtostartandstoptheengine,has
threepositions:off,run,andstart.
•Tostarttheengine,rotatethekeytotherunposition,
theglowpluglightwillcomeon.Whentheglow
pluglightturnsoff,turnthekeytothestartposition.
Releasethekeywhenenginestartsanditwillmove
automaticallytotherunposition.
•Tostoptheengine,rotatethekeytotheoffposition.
ThrottleLever
Movethecontrolforwardtoincreasetheenginespeed
andrearwardtodecreasespeed.
TractionControlLevers
•Tomoveforward,movethetractioncontrollevers
forward.Tomoverearward,movethetraction
controlleversrearward.
•Togostraight,movebothtractioncontrollevers
equally.
•Toturn,movetheleverlocatedonthesideyou
wanttoturnbacktowardtheneutralpositionwhile
keepingtheotherleverengaged.
14

Toro 22303 Specifications

General

Brand	Toro
Model	22303
Category	Compact Loader
Language	English
