Toro 30412 Groundsmaster 4000-D User Manual

3.Addgearoiltotheholeintheplanetary,ifnecessary,
tobringtheoiluptotheproperlevel.Installthe
plug.
4.Repeatsteps1-3ontheoppositegearassembly.
CheckingtheRearAxleLubricant
ServiceInterval:Every400hours
TherearaxleislledwithSAE85W-140gearlube.
Checktheoillevelbeforetheengineisrststartedand
every400hoursthereafter.Thecapacityis80oz(2.4l).
Visuallyinspectforleaksdaily.
1.Positionthemachineonalevelsurface.
2.Removeacheckplugfromoneendoftheaxle
(Figure12)andmakesurethatthelubricantisupto
thebottomofthehole.Ifthelevelislow,remove
thellplug(Figure12)andaddenoughlubricantto
bringtheleveluptothebottomofthecheckplug
holes.
Figure12
1.Checkplug
2.Fillplug
CheckingtheRearAxleGearBox
Lubricant
ServiceInterval:Every400hours
ThegearboxislledwithSAE85W-140gearlube.
Checktheoillevelbeforetheengineisrststartedand
every400hoursthereafter.Thecapacityis16oz(0.5l).
Visuallyinspectforleaksdaily.
1.Positionthemachineonalevelsurface.
2.Removethecheck/llplugfromtheleftsideofthe
gearbox(Figure13)andmakesurethatlubricant
isuptothebottomofthehole.Ifthelevelislow,
addenoughlubricanttobringtheleveluptothe
bottomofthehole.
Figure13
1.Gearbox2.Check/llplug
CheckingtheTirePressure
ServiceInterval:Beforeeachuseordaily
Thetiresareover-inatedforshipping.Therefore,
releasesomeoftheairtoreducethepressure.The
correctairpressureinthefrontandreartiresis25-30
psi(172-207kPa).
Important:Maintainevenpressureinalltiresto
ensureagoodquality-of-cutandpropermachine
performance.
Do not under -inate.
CheckingtheTorqueoftheWheelNuts
orBolts
ServiceInterval:Aftertherst10hours
Every200hours
Failuretomaintainpropertorqueofthewheel
nutscouldresultinfailureorlossofwheeland
mayresultinpersonalinjury.
Torquethefrontwheelnutsandrearboltsto85
to100ft-lb(115to136N⋅ ⋅
⋅
m)after1-4hoursof
operationandagainafter10hoursofoperation.
Torqueevery200hoursthereafter.
AdjustingtheHeight-of-Cut
FrontCuttingUnit
Theheight-of-cutisadjustablefrom1to5inches(25
to127mm)in1/2inch(13mm)increments.Toadjust
theheight-of-cutonthefrontcuttingunit,positionthe
castorwheelaxlesintheupperorlowerholesofthe
22
