Toro 30412 Groundsmaster 4000-D User Manual

Figure53
1.Batterycover
Figure54
1.Battery
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
3.Removetherubberbootfromthepositiveterminal
andinspectthebattery.
Batteryterminalsormetaltoolscouldshort
againstmetalcomponentscausingsparks.
Sparkscancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,do
notallowthebatteryterminalstotouchany
metalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
Incorrectbatterycableroutingcoulddamage
themachineandcablescausingsparks.Sparks
cancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Always disconnect thenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Always
connect thepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
4.CoatbothbatteryconnectionswithGrafo112X
(skin-over)grease,ToroPartNo.505-47,petroleum
jelly,orlightgreasetopreventcorrosion.Slidethe
rubberbootoverthepositiveterminal.
5.Installthebatterycover.
Fuses
Thereare8fusesintheelectricalsystem.Theyare
locatedbelowtheoperatorscontrolpanel(Figure55
andFigure56).
