BeltMaintenance
ServicingtheAlternatorBelt
ServiceInterval:Aftertherst10hours
Every100hours
Checktheconditionandtensionofthebelts(Figure63)
afterevery100operatinghours.
1.Propertensionwillallow3/8inch(10mm)
deectionwhenaforceof10lbisappliedonthe
beltmidwaybetweenthepulleys.
2.Ifthedeectionisnot3/8inch(10mm),loosen
thealternatormountingbolts(Figure63).Increase
ordecreasethealternatorbelttensionandtighten
thebolts.Checkthedeectionofthebeltagainto
ensurethatthetensioniscorrect.
Figure63
1.Alternator2.Mountingbolt
Re-tensioningtheBladeDrive
Belts
ServiceInterval:Aftertherst10hours
Every50hours
Checktheconditionandtensionofthecuttingunitdrive
beltsinitiallyafter8hoursofoperationandevery50
operatinghoursthereafter.
Whenproperlytensioned,theextensionspring(hook
tohook)measurementshouldbeapproximately3.50
±.25inch(inside).Oncethecorrectspringtensionis
attained,adjustthestopbolt(carriagebolt)untilthereis
approximately.125+.060/-.000inchclearancebetween
theheadoftheboltandtheidlerarm(Figure64).
Note:Makesurethebeltispositionedonthespring
sideofthebeltguide(Figure64).
Figure64
1.Belt4.Beltguide
2.Eyebolt5.Flangenut
3.Extensionspring
6.Stopbolt
ReplacingtheBladeDriveBelt
ServiceInterval:Every800hours
Thebladedrivebelt,tensionedbythespringloaded
idlerpulley,isverydurable.However,aftermanyhours
ofuse,thebeltwillshowsignsofwear.Signsofaworn
beltare:squealingwhenbeltisrotating,bladesslipping
whencuttinggrass,frayededges,burnmarksandcracks.
Replacethebeltifanyoftheseconditionsareevident.
1.Lowerthecuttingunittotheshopoor.Remove
thebeltcoversfromthetopofthecuttingunitand
setthecoversaside.
2.Loosentheeyeboltallowingtheremovalofthe
extensionspring(Figure64).
3.Loosentheangenutsecuringthestopbolttothe
mountingtab.Backoffthenutenoughtoallowthe
idlerarmtopassbythestopbolt(Figure64).Move
theidlerpulleyawayfromthebelttoreleasebelt
tension.
Note:Ifthestopboltiseverremovedfromthe
mountingtab,makesureitisreinstalledinthehole
thatalignsthestopboltheadwiththeidlerarm.
4.Removetheboltssecuringthehydraulicmotorto
thecuttingunit(Figure65).Liftthemotoroffofthe
cuttingunitandlayitontopofthecuttingunit.
