g019018
Figure33
1.Hexshaft
3.Rubberwheel
2.Steelfrictionpulley
Important:Donotgetoilontherubberwheelor
thesteelfrictionpulleybecausethetractiondrive
willslip(Figure33).
1.Drainthefuelfromthefueltank.
2.Tipthemachineforwardontoitsaugerhousing
andblockitsothatitcannotfall.
3.Removethebackcover(Figure34).
g019019
Figure34
1.Screws
4.Movethespeed-selectorlevertoPositionR2.
5.Dipyourngerinautomotiveengineoiland
lightlylubricatethehexshaft.
6.Movethespeed-selectorlevertoPosition6.
7.Lubricatetheotherendofthehexshaft.
8.Movethespeed-selectorleverforwardand
rearwardafewtimes.
9.Installthebackcoverandreturnthemachineto
theoperatingposition.
ReplacingtheSparkPlug
ServiceInterval:Every100hours—Replacethe
sparkplug.
WARNING
Replacingthesparkplugwhiletheengineis
hotcanresultinburns.
Waituntiltheengineiscooltoreplacethe
sparkplug.
UseaTorosparkplugorequivalent(Champion®
RN9YCorNGKBPR6ES).
1.Removetheboot(Figure35).
g016645
Figure35
1.Spark-plugboot
2.Cleanaroundthebaseofthesparkplug.
g016646
Figure36
3.Removeanddiscardtheoldsparkplug.
Note:Youwillneedaratchetwrenchextension
toremovethesparkplug.
4.Setthegapbetweentheelectrodesonanew
sparkplugat0.76mm(0.030inch)asshown
inFigure37.
24
