Contents
Page
Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fueling And Before Operating 2. . . . . . . . . .
While Operating 3. . . . . . . . . . . . . . . . . . . . .
Maintenance And Storage 3. . . . . . . . . . . . .
Safety and Instruction Decals 4. . . . . . . . . . .
Symbol Glossary 4. . . . . . . . . . . . . . . . . . . .
Assembly 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing The D-handle 5. . . . . . . . . . . . . . .
Installing The String Guard 5. . . . . . . . . . . .
Before Starting 5. . . . . . . . . . . . . . . . . . . . . . . . . .
Oil And Fuel 5. . . . . . . . . . . . . . . . . . . . . . .
Mixing Oil And Fuel 7. . . . . . . . . . . . . . . . .
Operation 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting/Stopping 7. . . . . . . . . . . . . . . . . . . .
Adjusting The Trimming Line Length 8. . . .
Decorative Trimming 8. . . . . . . . . . . . . . . . .
Maintenance 8. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 8. . . . . . . . . . . . . . . .
Line Installation 8. . . . . . . . . . . . . . . . . . . . .
Installing A Prewound Reel 9. . . . . . . . . . . .
Air Filter Maintenance 10. . . . . . . . . . . . . . . .
Carburetor Adjustment 10. . . . . . . . . . . . . . . .
Replacing The Spark Plug 11. . . . . . . . . . . . .
Inspecting/Cleaning The Muffler 12. . . . . . . .
Cleaning 12. . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 13. . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 14. . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 14. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Shaft & Cutting Head 14. . . . . . . . . . .
Cold Engine Torque Specifications 14. . . . . .
California Emission Control Warranty Statement 15
Warranty 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Thank you for purchasing a Toro product.
All of us at Toro want you to be completely satisfied
with your new product, so feel free to contact your
local Authorized Service Dealer for help with service,
genuine Toro parts, or other information you may
require.
Whenever you contact your Authorized Service
Dealer or the factory, always know the model and
serial numbers of your product. These numbers will
help the Service Dealer or Service Representative
provide exact information about your specific
product. You will find the model and serial number
decal located in a unique place on the product
(Fig. 1).
For your convenience, write the product model and
serial numbers in the space below.
Model No.
Serial No.
Read this manual carefully to learn how to operate
and maintain your product correctly. Reading this
manual will help you and others avoid personal injury
and damage to the product. Although Toro designs,
produces and markets safe, state-of-the-art products,
you are responsible for using the product properly
and safely. You are also responsible for training
persons who you allow to use the product about safe
operation.
The Toro warning system in this manual identifies
potential hazards and has special safety messages that
help you and others avoid personal injury, even death.
DANGER, WARNING and CAUTION are signal
words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
