WheretoAddGrease
Figure21
ItemName
Quantity
(pumps)
Interval(hours)
Lubricant
1
Frontwheel—greasettings
225
Grease
2
Steeringballjoints
450
Oil
3
Steeringsectorgear
150
Grease
4
Steeringpiniongear
125
Grease
5
Steeringshaftbearing
150
Oil
6
Steeringshaftbearing
150
Oil
7
Motionlever150
Grease
8
Shafthubforliftingthemowerhousing
150
Oil
9Motionlinkballjoints450
Oil
10
Tractionidlerpulleybelt—greasetting
150
Grease
11
Brakepedalshaftpivotpoints
250
Oil
12
Parkingbrakering150
Oil
13
Steeringbearing
125
Grease
14
LeftandRightSpindle—greasettings
225
Grease
15Mowerhousinghingedpins6Whenremoved
Grease
16
Frontaxlepivotpins2Whenremoved
Grease
EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every25hours—Servicetheaircleaner
foamelement.(Serviceitmorefrequently
whenoperatingthemachineindustyor
dirtyconditions.)
Every100hours—Servicetheaircleanerpaper
element.(Serviceitmorefrequentlywhenoperating
themachineindustyordirtyconditions.)
1.Parkthemachineonalevelsurface.
2.Disengagetheblades(PTO).
3.Settheparkingbrake.
4.Stoptheengineandwaitforallmovingpartstostop.
5.Removetheignitionkey.
RemovingtheFoamandPaper
Elements
1.Cleanaroundtheaircleanertopreventdirtfrom
gettingintotheengineandcausingdamage.
