3.Usingtheboltandwingnut,connectthepositive(red)
cabletothepositive(+)batterypost(Figure33).Slide
therubbercoveroverthebatterypost.
4.Usingtheboltandwingnut,connectthenegative
(black)cabletothenegative(–)batterypost(Figure33).
Slidetherubbercoveroverthebatterypost.
CheckingtheElectrolyteLevel
ServiceInterval:Beforeeachuseordaily
1.Tiptheseatforwardtoseethebattery.
2.Lookatthesideofthebattery.Theelectrolytemustbe
uptotheupperline(
Figure34).
Figure34
1.Fillercaps3.Lowerline
2.Upperline
Note:donotallowtheelectrolytetofallbelowthe
lowerline(Figure34).
3.Iftheelectrolyteislow,addtherequiredamountof
distilledwater;refertoAddingWatertotheBattery.
DANGER
Batteryelectrolytecontainssulfuricacid
whichisadeadlypoisonandcausessevere
burns.
•Donotdrinkelectrolyteandavoidcontact
withskin,eyesorclothing.Wearsafety
glassestoshieldyoureyesandrubber
glovestoprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryisjust
beforeyouoperatethemachine.Thisletsthewatermix
thoroughlywiththeelectrolytesolution.
1.Cleanthetopofthebatterywithapapertowel.
2.Removethellercaps(
Figure34).
3.Slowlypourdistilledwaterintoeachbatterycelluntil
thelevelisuptothelowerpartofthetube(Figure34).
Important:Donotoverllthebattery.Electrolyte
(sulfuricacid)canseverelycorrodeanddamage
thechassis.
4.Replacethellercaps.
ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.Neversmokenearthebatteryandkeep
sparksandamesawayfromthebattery.
Important:Alwayskeepthebatteryfullycharged(1.260
specicgravity),especiallybelow32°F(0°C)toprevent
batterydamage.
1.Removethebatteryfromthechassis;refertoRemoving
theBattery.
2.Checktheelectrolytelevel;refertoCheckingthe
ElectrolyteLevel.
3.Removethellercapsfromthebatteryandconnecta
2ampbatterychargertothebatteryposts.
4.Chargethebatteryatarateof2ampsorlessfor4
hours(12volts).Donotoverchargethebattery.
5.Whenthebatteryisfullycharged,installthellercaps.
6.Installthebatteryinthechassis;refertoInstallingthe
Battery.
26
