Installing the Cutting Unit (continued)
G404930
3. Move the suspension latches down to
secure the cutting unit to the machine.
4. Move the collar
out of the transmission-
coupler-shaft groove and insert the hex tube
into the cutting-unit coupler shaft .
5. Install the grass basket.
Removing the Cutting Unit
Note: The hex tube disengages if you engage the reel drive when the cutting unit is
removed.
1. Move the kickstand to the C
UTTING-UNIT-SERVICE position.
2. Remove the grass basket (if equipped).
3. Move the collar
into the transmission-shaft groove.
Note: This releases tension from the spring.
