Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use the chart below to verify that all parts have been shipped.
Description Qty. Use
Steering wheel
Foam seal
Nut
Screw
Cap
1
1
1
1
1
Installing the steering wheel
Manual tube (shipped in tool box)
R-clamp
1
2
Holding the operator’s manual. Install on right
underside of seat.
Right-hand ball joint (shipped in tool box) 1
Install ball joint (implement installation) and
connect lift cylinder
Hydraulic oil filter 1 Change after 10 hours
Parts catalog 1
Operator’s Manual (traction unit) 2 Read before operating the machine.
Engine Dealer Listing 1
Operator Video 1 Watch before operating the machine.
Registration card 1 Fill out and return to Toro.
