Toro ProLine H800 User Manual

CheckingforWaterintheFuel
Bowl
1.Lookatthewaterindicatorinthefuel-lterbowl
todetermineiftheoatiselevatedbywaterin
thefuel-lterbowl(Figure66).
g231812
g231813
Figure66
2.Ifthereiswaterinthefuel-lterbowl,rotatethe
fuelshutoffvalveforthefuel/waterseparator
totheCLOSEDposition(Figure67)andperform
thestepsinDrainingWaterfromtheFuelBowl
(page54).
g231811
Figure67
DrainingWaterfromtheFuelBowl
1.Placeadrainpanunderthefuel-lterbowl,
removethebowlnut,andremovethelterbowl
fromthelterhead(Figure68).
Note:Youwillremovethespringandtheoat
whenyouremovethelterbowl.
g231810
Figure68
1.Filterhead4.Float
2.O-ring5.Fuel-lterbowl
3.Spring
6.Bowlnut
2.Emptythelterbowloffuelandwater.
3.Atthelterhead,checktheconditionofthe
O-ring(Figure68).
Note:ReplacetheO-ringifitiswornor
damaged.
4.LubricatetheO-ringwithcleanfuel.
5.Assemblethespringandoatintothefuel-lter
bowl(Figure68).
6.Assemblethelterbowlandbowlnutontothe
lterheadandtightenthenutbyhand(Figure
68).
7.Openthefuelshutoffvalveandifneededprime
thefuelsystem;refertoPrimingtheFuelSystem
(page53).
8.Checkthefuel/waterseparatorforleaks.
Note:Repairallfuelleaksbeforeoperatingthe
machine.
54
