Figure92
1.Hole(PTO-clutchplate)
3.Anti-rotationtube
2.Pin(anti-rotationtube)
8.Loosenthenutfortheidler-pulleytensioner;
refertoFigure89inCheckingthePTOBelt
Tension(page65).
9.Rotatetheidlerpulleytowardtheengineand
removethebeltsfromthemachine(Figure93).
g232232
Figure93
InstallingthePTOBelts
1.AlignthebePTObeltsoverthepulleys(Figure
94).
g232323
Figure94
1.Clutchpulley3.PTO-shaftpulley
2.Idlerpulley
2.Alignthepinoftheanti-rotationtubewiththe
holeinthePTO-clutchplate;refertoFigure92
inRemovingthePTOBelts(page65).
3.Securetheanti-rotationtubetotherightengine
mountwiththe2boltsand2nutsthatyou
removedinstep6ofRemovingthePTOBelts
(page65).
4.Hooktheclutch-damperspringbetweenthe
inboardclutch-plateboltandthespringbracket;
refertoFigure90inRemovingthePTOBelts
(page65).
5.Tightenthenutfortheidler-pulleytensioner;
refertoCheckingthePTOBeltTension(page
65).
6.Closetheradiatortothemachine;referto
AccessingtheEnginefromtheRightside(page
49).
