Toro Super Recycler 20381 User Manual

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
Interval
MaintenanceProcedure
Aftertherst5hours
•Changetheengineoil.
Beforeeachuseordaily
•Checktheengineoillevel.
•Cleangrassclippingsanddirtfromunderthemachine.
•Ensurethattheenginestopswithin3secondsafterreleasingtheblade-controlbar.
Every25hours
•Chargethebattery.
•Lubricatetherearwheelgears.
•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).
Beforestorage
•Chargethebattery.
•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.
Yearly
•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.
•Changetheengineoil.
MaintenanceSafety
•Disconnectthespark-plugwirefromthesparkplugand
removetheelectric-startbuttonbeforeperformingany
maintenanceprocedure.
•Wearglovesandeyeprotectionwhenservicingthe
machine.
•Thebladeissharp;contactingthebladecanresultin
seriouspersonalinjury.Weargloveswhenservicingthe
blade.
•Nevertamperwithsafetydevices.Checktheirproper
operationregularly.
•Tippingthemachinemaycausethefueltoleak.Fuelis
ammableandexplosive,andcancausepersonalinjury.
Runtheenginedrytoremovethefuelwithahandpump;
neversiphonthefuel.
PreparingforMaintenance
1.Stoptheengine,removetheelectric-startbutton,and
waitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthesparkplug
(Figure36)beforeperforminganymaintenance
procedure.
G017466
1
Figure36
1.Spark-plugwire
Important:Beforetippingthemachinetochange
theoilorreplacetheblade,allowthefueltankto
rundrythroughnormalusage.Ifyoumusttip
themachinepriortorunningoutoffuel,usea
handfuelpumptoremovethefuel.Alwaystipthe
machineontoitssidewiththeairlterup.
3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.
19

Toro Super Recycler 20381 Specifications

General

Engine Type	4-Cycle
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Starter	Recoil
Warranty	5-Year Full
Engine	Briggs & Stratton
Drive System	Personal Pace Rear-Wheel Drive
Cutting Width	21 inches
Fuel Capacity	1.0 Quarts
