G017459
Figure39
1.Theoillevelisatits
maximum.
3.Theoillevelistoo
low—addoiltothe
crankcase.
2.Theoillevelistoo
high—removeoilfrom
thecrankcase.
•Iftheoillevelistoolow,addasmallamountof
oilslowlytotheoil-lltube,andthenrepeatsteps
6through8untiltheoillevelonthedipstickis
correct.
•Iftheoillevelistoohigh,draintheexcessoiluntil
theoillevelonthedipstickiscorrect.
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
9.Installthedipsticksecurely.
10.Recycletheusedoilproperly.
ChargingtheBattery
ServiceInterval:Every25hours
Beforestorage
Electric-startmodelonly
WARNING
Batteryposts,terminals,andrelatedaccessories
containleadandleadcompounds,chemicals
knowntotheStateofCaliforniatocausecancer
andreproductiveharm. W ash hands after handling
batter y .
Chargethebatteryfor24hoursinitially,thenmonthly(every
25starts)orasneeded.Alwaysusethechargerinasheltered
areaandchargethebatteryatatemperaturebetween0°C
(32°F)and41°C(105°F)wheneverpossible.
1.Connectthechargertothemachinewiringharness
locatedbelowtheelectric-startbutton(Figure40).
Figure40
2.Plugthechargerintoawalloutlet.
Note:Whenthebatterynolongerholdsacharge,
recycleordisposeofthelead-acidbatteryaccording
tolocalcodes.
Note:Yourbatterychargermayhavea2-colorLEDdisplay
thatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischargingthe
battery.
•Agreenlightindicatesthatthechargerisfullychargedor
thechargerisdisconnectedfromthebattery.
•Aashinglightthatalternatesbetweenredandgreen
indicatesthatthebatteryisnearlyfullycharged.Thisstate
lastsonlyafewminutesuntilthebatteryisfullycharged.
ReplacingtheFuse
Electric-startmodelonly
Ifthebatterydoesnotchargeortheenginedoesnotturn
withtheelectricstarter,thefusemaybeblown.Replaceit
witha40-ampplug-intypefuse.
Important:Youcannotstartthemachinewiththe
electricstarterorchargethebatteryunlessyouinstall
thefuse.
1.RefertoPreparingforMaintenance(page19).
2.Unclipbothendsofthebatterycoverandremoveit
(Figure41).
G017476
Figure41
3.Replacethefuseinthefuseholder(Figure42).
21

Toro Super Recycler 20381 Specifications

General

Engine Type	4-Cycle
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Starter	Recoil
Warranty	5-Year Full
Engine	Briggs & Stratton
Drive System	Personal Pace Rear-Wheel Drive
Cutting Width	21 inches
Fuel Capacity	1.0 Quarts
