ProductOverview
G027603
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Figure9
1.Cutting-heightlever(4)
8.Blade-controlbar
2.Sparkplug
9.Upperhandle
3.Oilll/Dipstick(notshown)
10.Electric-start
button(electric-startmodel
only)
4.Fueltankcap
11.Grassbag
5.Dischargedeector12.Battery(electric-start
modelonly)
6.Recoilstarthandle13.Washoutport
7.Adjustmentknobforthe
self-propeldrive
14.Airlter
Figure10
1.Grassbag
3.Batterycharger
(electric-startmodelonly)
2.Side-dischargechute
4.Rear-dischargeplug
(installed)
Operation
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
•Checkthatallguardsandsafetydevices,suchasdeectors
and/orgrasscatcher,areinplaceandworkingproperly.
•Alwaysinspectthemachinetoensurethattheblades,
bladebolts,andcuttingassemblyarenotwornor
damaged.
•Inspecttheareawhereyouwillusethemachineand
removeallobjectsthatthemachinecouldthrow.
•Adjustingthecuttingheightmaybringyouintocontact
withthemovingblade,causingseriousinjury.
–Shutofftheengine,removetheelectric-startbutton,
andwaitforallmovingpartstostop.
–Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
FuelSafety
DANGER
Fuelisextremelyammableandhighlyexplosive.
Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.
•Topreventastaticchargefromignitingthefuel,
placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.
•Fillthefueltankoutdoors,inanopenarea,when
theengineiscold.Wipeupanyfuelthatspills.
•Donothandlefuelwhensmokingoraroundan
openameorsparks.
•Storefuelinanapprovedcontainerandkeepit
outofthereachofchildren.
WARNING
Fuelisharmfulorfatalifswallowed.Long-term
exposuretovaporscancauseseriousinjuryand
illness.
•Avoidprolongedbreathingofvapors.
•Keepyourhandsandfaceawayfromthenozzle
andthefuel-tankopening.
•Keepfuelawayfromyoureyesandskin.
9

Toro Super Recycler 20381 Specifications

General

Engine Type	4-Cycle
Deck Material	Cast Aluminum
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge Capability	Yes
Starter	Recoil
Warranty	5-Year Full
Engine	Briggs & Stratton
Drive System	Personal Pace Rear-Wheel Drive
Cutting Width	21 inches
Fuel Capacity	1.0 Quarts
