Toro Super Recycler 20382 User Manual

131–4514
1.Warning—readtheOperator'sManual.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.
3.Cutting/dismembermenthazardofhandorfoot,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.
4.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine;stoptheenginebeforeleavingthe
operatingposition;pickupanydebrisbeforemowing.
5.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotoperateupanddownslopes;operatesideto
sideonslopes;lookbehindyouwhenbackingup.
Setup
1
AssemblingandUnfoldingthe
Handle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenassemblingand
unfoldingthehandle.
•Ensurethatthecablesareroutedtotheoutside
ofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemachinehousingtoits
highestcutting-heightsettingbymovingthe2rear
cutting-heightleversallthewayforward.Referto
AdjustingtheCuttingHeight(page10).
2.Attachthehandleendstothemachinehousingwith
2washersand2handlebolts(Figure3),butdonot
tightenthehandlebolts.
G017457
Figure3
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe outside ofthe
handle(Figure3).
3.Rotatethehandlerearward(Figure4).
5
