Toro TimeMaster 21199 User Manual

ChargingtheBattery
Electric-StartModelOnly
ServiceInterval:Every25hours
Yearlyorbeforestorage
Chargethebatteryfor24hoursinitially,thenmonthly
(every25starts)orasneeded.Alwaysusethe
chargerinashelteredarea,andchargethebattery
atroomtemperature(about22°Cor70°F)whenever
possible.
Note:Themachineisnotequippedwithanalternator
chargingsystem.
1.Connectthechargertothewireharnesslocated
belowtheignitionkey(Figure31).
g017518
Figure31
2.Plugthechargerintoawalloutlet.
Note:Whenthebatterynolongerholdsa
charge,recycleordisposeofthelead-acid
batteryaccordingtolocalcodes.
Note:Yourbatterychargermayhavea2-colorLED
displaythatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischarging
thebattery.
•Agreenlightindicatesthatthechargerisfully
chargedorisdisconnectedfromthebattery.
•Aashinglightthatalternatesbetweenredand
greenindicatesthatthebatteryisnearlyfully
charged.Thisstatelastsonlyafewminutesuntil
thebatteryisfullycharged.
ReplacingtheFuse
Electric-StartModelOnly
Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.
Replaceitwitha40Aplug-intypefuse.
Important:Youcannotstartthemachinewith
theelectricstarterorchargethebatteryunlessa
workingfuseisinstalled.
1.Openthesealedfuseholderandreplacethe
fuse(Figure32).
g020856
Figure32
1.Fuseholder
2.Closethecovertothefuseholder,andensure
thatitissealedtightly.
ReplacingtheBattery
Electric-startmodelonly
RemovingtheOldBattery
1.ContactanAuthorizedServiceDealertoobtain
areplacementbattery.
2.Removethebeltcover;refertostep1of
ServicingtheBlade-DriveSystem(page26).
3.Removetherear-dischargeplug.
4.Movethehandletotheverticalposition.
5.Removethe4smallboltsthatholdtherear
deectorandhandle-lock-leverassemblyin
place.
6.Foldthehandleallthewayforward.
7.Removethereardeectorandhandle-locklever
assembly(Figure33).
24

Toro TimeMaster 21199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Deck Material	Steel
Mulching Capability	Yes
Warranty	3-Year Full Warranty
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Speed Range	0 - 4.5 mph (0 - 7.2 km/h)
