Toro TimeMaster 21199 User Manual

InstallingtheBlades
1.Installtherstbladesothatitishorizontal,along
withallmountinghardwareasshowninFigure
41.
Note:Tightentheboltwithyourngers.
Important:Positionthecurvedendsofthe
bladestopointtowardthemachinehousing.
Besuretonesttheraisedareasoneach
bladedriverwiththerecessesintheheadof
itscorrespondingspindle,andthepinson
theothersideofeachbladedriverwiththe
holesinitscorrespondingblade.
2.Steadyeachbladewithaboardandturnthe
bladeboltclockwisewithatorquewrenchas
showninFigure42;torquethebladeboltto82
N∙m(60ft-lb).
g232801
Figure42
3.Rotatetheinstalledblade1/4turnuntilitis
vertical,andinstalltheotherbladeinthesame
mannerastherst(refertostep1).
Note:Thebladesshouldbeperpendicular,
forminganinverted“T”asshowninFigure43.
g016536
Figure43
1.Blade(2)
4.Tightenthesecondblade;refertostep2.
5.Rotatethebladesbyhandafull360°turnto
ensurethattheydonottouch.
Note:Ifthebladestoucheachother,theyare
notmountedcorrectly.Repeatsteps1through
3,untilthebladesnolongertoucheachother.
WARNING
Incorrectlyinstallingthebladescoulddamage
themachineorcauseaninjurytoyouor
bystanders.
Usecarewheninstallingtheblades.
29

Toro TimeMaster 21199 Specifications

General

Engine Displacement	223cc
Cutting Width	30 inches
Deck Material	Steel
Mulching Capability	Yes
Warranty	3-Year Full Warranty
Cutting Height	1.25 - 4.25" (3.2 - 10.8 cm)
Speed Range	0 - 4.5 mph (0 - 7.2 km/h)
