WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalcomponents,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthetractionunit.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
tractionunit.
RemovingtheBattery
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Lifttheblackrubbercoveronthenegativecable.
Disconnectthenegativebatterycablefromthe
negative(-)batteryterminal(Figure40).
g008335
Figure40
1.Negativecable7.Positivecable
2.Nut(1/4inch)
8.Batteryholddownplate
3.Nut(5/16inch)
9.Washer
4.Bolt10.J-bolt
5.Rubbercover(red)
11.Battery
6.Rubbercover(black)
4.Slidetheredterminalbootoffthepositive(red)
batteryterminal.Thenremovethepositive(red)
batterycable(Figure40).
5.Removetheholddownplate,j-bolts,and
locknutssecuringthebattery(Figure40)and
removethebattery.
ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthat
canexplode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity).Thisisespecially
importanttopreventbatterydamagewhenthe
temperatureisbelow0°C(32°F).
1.Removethebatteryfromthemachine;referto
RemovingtheBattery(page32).
2.Chargethebatteryatarateof3to4Afor4
to8hours(Figure41).Donotoverchargethe
battery.
g003792
Figure41
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
3.Whenthebatteryisfullycharged,unplug
thechargerfromtheelectricaloutlet,then
disconnectthechargerleadsfromthebattery
posts(Figure41).
32
