CheckingtheBatteryElectrolyte
Level
DANGER
Batteryelectrolytecontainssulfuricacid
whichisfatalifconsumedandcausessevere
burns.
•Donotdrinkelectrolyteandavoidcontact
withskin,eyesorclothing.Wearsafety
glassestoshieldyoureyesandrubber
glovestoprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Lookatthesideofthebattery.Theelectrolyte
mustbeuptotheupperline(Figure42).Do
notallowtheelectrolytetofallbelowtheLower
line(Figure42).
g000537
Figure42
1.Ventcaps3.Lowerline
2.Upperline
4.Iftheelectrolyteislow,addtherequiredamount
ofdistilledwater;refertoAddingWatertothe
Battery(page33).
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryis
justbeforeyouoperatethemachine.Thisletsthe
watermixthoroughlywiththeelectrolytesolution.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Removethebatteryfromthemachine;referto
RemovingtheBattery(page32).
Important:Neverllthebatterywith
distilledwaterwhilethebatteryisinstalledin
themachine.Electrolytecouldspillonother
partsandcausecorrosion.
4.Cleanthetopofthebatterywithapapertowel.
5.Removetheventcapsfromthebattery(Figure
42).
6.Slowlypourdistilledwaterintoeachbatterycell
untiltheelectrolytelevelisuptotheUpperline
(Figure42)onthebatterycase.
Important:Donotoverllthebattery;
electrolyte(sulfuricacid)cancausesevere
corrosionanddamagetothechassis.
7.Wait5to10minutesafterllingthebattery
cells.Adddistilledwater,ifnecessary,untilthe
electrolytelevelisuptotheUpperline(Figure
42)onthebatterycase.
8.Installthebatteryventcaps.
CleaningtheBattery
Note:Keeptheterminalsandtheentirebatterycase
clean,becauseadirtybatterydischargesslowly.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Removethebatteryfromthemachine;
RemovingtheBattery(page32).
4.Washtheentirecasewithasolutionofbaking
sodaandwater.
5.Rinsethebatterywithclearwater.
6.Coatthebatterypostsandcableconnectorswith
Grafo112X(skin-over)grease(T oroPartNo.
505-47)orpetroleumjellytopreventcorrosion.
7.Installthebattery;refertoInstallingtheBattery
(page33).
InstallingtheBattery
1.Usingthefastenerspreviouslyremoved,install
thepositive(red)batterycabletothepositive(+)
batteryterminal(Figure41).
2.Slidetheredterminalbootontothepositive
batterypost.
3.Usingthefastenerspreviouslyremoved,install
thenegative(black)batterycabletothenegative
(-)batteryterminal(Figure41).
4.Securethebatteryusingthebarandwingnuts
(Figure41).
Important:Ensurethatthebatterycablesdonot
contactanysharpedgesoreachother.
33
