12
Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Type
4 wheel step through, out front operator style, two person vehicle. Certified to meet
SAE J2258.
Engine
Kohler, 4 cycle, air cooled, 23 hp @ 3600 rpm, 41.1 cu. in. (674 cc) displacement.
Mechanical fuel pump, 2 qt. oil capacity. Large capacity dual element air cleaner.
Battery 12 volt with 525 cold cranking Amps @ 0 degrees F.
Fuel System Gasoline tank capacity is 7 gallons. 12 volt, electric fuel pump.
Transmission
Rear transaxle configuration, twin axle drive. 3 speed synchromesh, H–shift pattern
with high–low range providing 6 forward and 2 reverse speeds. Manual engage
differential lock.
Clutch 6.7” clutch and pressure plate.
Frame Welded, high strength steel construction.
Front Suspension
Independent “A” frame control arm, dual progressive rate coil springs and dual
shock absorbers with anti–sway bar.
Rear Suspension
DeDion axle (weight carrying axle is independent of transaxle), leaf spring and dual
shock absorbers.
Steering System Power steering, 3–3/4 turns lock–to–lock. 14” diameter steering wheel.
Tires
Front tires: 20” x 10”-10, 4-ply rating, rib tread.
Rear tires: 24” x 12”-12, 6-ply rating, turf tread.
Brakes
4 wheel hydraulic, dual safety circuit self adjusting drum: 8” diameter front and rear.
Hand actuated parking brake actuates rear brake shoes.
ROPS 2 post roll over protection structure.
Hydraulics
4 gpm pressure balanced gear pump provides hydraulic flow for power steering, lift
and optional remote hydraulics. Lift control valve and dual cylinders for lifting dump
box. Transaxle is used for reservoir for hydraulic system. 8 quart total capacity.
Spin–on 25 micron hydraulic oil filter. 100 mesh strainer in transaxle.
Seat
Bucket seats with seat belts and hip restraints. 7” fore and aft adjustment for
comfort.
Controls
Foot operated accelerator, clutch and brake pedals. Hand operated shifter,
differential lock, parking brake, high–low range shifter, hydraulic lift and tilt steering
levers. Ignition switch, light switch, choke knob, horn button and 3rd high lockout
switch.
Gauges Hour meter, oil pressure warning light and fuel gauge.
Lights Twin halogen headlights and single taillight. Rear stop light.
Tow Hitch Hitch has hole for ball or pin.
Interlocks Clutch pedal must be depressed to start engine or disengage PTO, if so equipped.
Ground Speed
Forward Speeds w/24” Rear Tires
High range: 7.6/11.5/19.8 mph
Low range: 2.9/4.5/7.7 mph
Reverse Speeds w/24” Tires
High range: 7.2 mph
Low range: 2.8 mph
