MaintainingthePrimary
DriveClutch
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
CAUTION
Thedustintheclutchwillbecomeairborne
andcoulddamageyoureyesoryoucould
inhaleit,causingbreathingdifculties.
Wearsafetygogglesandadustmaskor
othereyeandrespiratoryprotectionwhen
performingthisprocedure.
1.Raiseandlatchthecargobed.
2.Removethe3boltssecuringthecovertothe
clutch,andremovethecover(Figure58).
Note:Retainthecoverandboltsforinstallation.
g011947
Figure58
1.Cover
2.Bolts
3.Thoroughlycleantheinsideofthecoverand
theinnercomponentsoftheclutchusing
compressedair.
4.Installtheclutchcoverandsecureitwiththe3
bolts(Figure58)thatyouremovedin2.
5.Lowerthecargobed.
ReducingtheTopSpeed
CAUTION
Thedustintheclutchwillbecomeairborne
andcoulddamageyoureyesoryoucould
inhaleit,causingbreathingdifculties.
Wearsafetygogglesandadustmaskor
othereyeandrespiratoryprotectionwhen
performingthisprocedure.
1.Raiseandlatchthecargobed;refertoRaising
theCargoBedtotheServicePosition(page19).
2.Removetheboltssecuringtheprimaryclutch
coverasshowninFigure59.
Important:Usecautionwhenremoving
theclutchcover;thespringisunder
compression.
Important:TakenoteoftheXorientation
ontheclutchcoversandclutchassemblies
forlaterinstallation.
g026341
Figure59
1.Clutchspacer
3.Removethespring.
4.Addorremovespacerstoadjustthetopspeed.
Usethefollowingtabletodeterminetheamount
ofspacersneeded.
SpacersTopSpeed
2(standard)16mph(standard)
312mph
49mph
5
6mph
64mph
Important:Donotoperatethemachine
withoutatleast2clutchspacersinplace.
5.Installthespringandclutchcover.
