Toshiba 1000 Series User Manual

24
7.5 UPS Meters Display
Listed below are the parameters available for viewing from the UPS meters display.
Press this button to scroll through the parameters.
LCD Message
Description
O/P VOLT= xxx.xV
Shows Output AC Voltage
O/P FREQ= xx.x Hz
Shows Output Frequency
I/P VOL T= xxx.xV
Shows Input AC Voltage
I/P FREQ= xx.x Hz
Shows Input Frequency
BAT VOLT= xx.xV
Shows Battery Voltage
O/P LOAD%= xx%
Shows Load % of Max Load
O/P W= xW
Shows Output Watts
O/P VA= xVA
Shows Output VA
O/P CURR= xA
Shows Output Current
BACKUP TIME= xx min
Shows Estimated Backup Time in Minutes
BAT CHARG= xx%
Shows Approximate Percentage of Battery Capacity
TEMPERATURE= xxC
Shows Approximate Ambient Temperature
BAT PACK NUM= x
Shows External Battery Pack Number
RATING = xxxxVA
Shows UPS Rating
CPU VERSION xx.x
Shows CPU Version
7.6 UPS Configurations
1) Parameter settings may be viewed from the UPS Settings display.
2) To enter the configuration mode, press and hold the Function button for one second.
The first configuration parameter will be shown on the LCD display.
3) Press the Function button again to scroll through the remaining parameters.
