Appendix
Specifications
• This model complies with the specifications below.
• Design and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
14AF46 20AF46
Picture Tube 14 in. (357 mm) diagonal 20 in. (508 mm) diagonal
(Screen size is approximate.) (Screen size is approximate.)
Television system NTSC standard
Channel coverage VHF: 2–13
UHF: 14–69
Cable TV: 4A, A-5–A-1, A-I,
J–W, W
+
1–W
+
84
Power source 120V AC, 60 Hz
Power consumption 80 W 105 W
Audio power 2.5 W + 2.5 W
Speaker type 1-5/8 in. x 2-13/16 in. x 2 pcs. 2 in. x 4-11/16 in. x 2 pcs.
Video/Audio terminals S-VIDEO INPUT
Y-INPUT: 1V (p-p), 75 ohm, negative sync.
C-INPUT: 0.286V (p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
ColorStream
®
(component video) INPUT
Y : 1V (p-p), 75 ohm
PR : 0.7V (p-p), 75 ohm
PB : 0.7V (p-p), 75 ohm
Dimensions Width: 17 in. (432 mm) 23-1/4 in. (590 mm)
Height: 13-9/16 in. (344.5 mm) 17-9/16 in. (446.5 mm)
Depth: 15-3/16 in. (386 mm) 19-1/16 in. (484 mm)
Weight 24.3 lbs. (11 kg) 50.6 Ibs. (23 kg)
Supplied accessories Remote control with two size “AAA” batteries
