ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
DIODES
D7014 AE009006 DGERMA1110 DIODE SILICON MA111-(TX)
D7017 AE009006 DGERMA1110 DIODE SILICON MA111-(TX)
D7018 AE009006 DGERMA1110 DIODE SILICON MA111-(TX)
D7024 AE009006 DGERMA1110 DIODE SILICON MA111-(TX)
D7601 AE000288 0021E9Q010 LED LTL-1BEFJ-002A
D8101 AE011519 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D8510 AE009006 DGERMA1110 DIODE SILICON MA111-(TX)
ICS
!
IC301 AE008430 I03SP20520 SOUND AMP 5W 2CH LA42052-E
!
IC501 AE016759 ICAL055710 POWER IC CONTROL FA5571N-D1-TE1
!
IC502 AE011889 I1KJ9A431A VARIABLE SHUNT REGULATOR TAPE KIA431A-AT
!
IC503 AE009500 I03F9797M0 CHARGE POMP CONTROL LA5797M-TE-L-E
!
IC505 AE002809 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
!
IC2301 AE008194 I03FV65650 5CH MOTOR DRIVER IC LA6565VR-TLM-E
IC2801 AE016760 I56M069550 SCALER R8J66955BG
IC2802 AE016761 IGXM05162E DDR2-800 512M CL=5 H5PS5162FFR-S5C
IC2803 AE017014 S52E01CE02 MEMORY DATA EEPROM 256K 12C AT24C256BN-10SU-1.8
IC2806 AE016763 ICRJ0256B0 EEPROM 256K 12C AT24C256BN-10SU-1.8
IC3004 AE009719 I5HJ950UC0 REGULATOR VO=5.0V IO=800MA S-1170B50UC-OUJTFG
!
IC3006 AE016764 I07F993230 DC-DC CONVERTER 3.0A BD9323EFJ
!
IC3007 AE016764 I07F993230 DC-DC CONVERTER 3.0A BD9323EFJ
!
IC3008 AE016765 IGRF0704U0 2A DROPOUT LINEAR REGULATOR UP7704U8
IC3601 AE017016 S52E01CE03 MEMORY DATA EEPROM 2K 12C S-24CS02AFJ-TB-GE
IC4001 AE009720 ICQK06966A VADDIS9 MPEG/MICON/DSP/RF-AMP ZR36966ELCG-D-G
IC4005 AE016766 IG2J081656 SDRAM 166MHZ 4*16MBIT 54PIN EM638165TS-6G(0.11UM-N)
IC6201 AE011998 I9UF032290 RESET IC 2.9V TYPE PST3229NR
IC6501 AE016768 I55J040520 DUAL 4CH ANALOG MULTIPLEXER TC74LVX4052FT
IC6502 AE009928 I55F0A53FU A/V SW 2IN 1OUT TC7PA53FU(T5L,F,T)
IC7001 AE016769 I07F098930 INVERTER CONTROL IC BD9893F-E2
IC8501 AE009365 I0QF045650 DUAL OPEAMP NJM4565M(TE1)
!
IC8502 AE009805 I1YF9117A0 VO=ADJ IO=1A TAPING LD1117AL-ADJ-AA3-A-R
TRANSISTORS
TRANSISTORS
!
Q501 AE016770 TJA0N50FS0 FET KHB9D0N50F2-U/P
Q503 AE013033 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK
Q504 AE013011 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK
Q505 AE012926 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
Q2301 AE012926 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
Q2302 AE008330 TAAA1505SY TRANSISTOR SILICON KTA1505S-Y-RTK/P
Q3001 AE013010 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q3002 AE013031 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK
Q3003 AE013010 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q3004 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3005 AE013011 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK
Q3006 AE005049 TNAAA05001 COMPOUND TRANSISTOR KRC101S-RTK
!
Q3007 AE009621 TL4A01664Y TRANSISTOR SILICON KTA1664-Y(GP)
Q3008 AE016771 TK9A3443B0 FET SI3443BDV-T1-E3
Q3009 AE005049 TNAAA05001 COMPOUND TRANSISTOR KRC101S-RTK
Q3010 AE016771 TK9A3443B0 FET SI3443BDV-T1-E3
Q3011 AE016771 TK9A3443B0 FET SI3443BDV-T1-E3
Q3012 AE013010 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q3402 AE013031 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK
Q3404 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3407 AE013010 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q3409 AE013031 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK
Q3410 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3411 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3604 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3607 AE016772 T27T035410 FET 2SK3541_T2L
Q3608 AE016772 T27T035410 FET 2SK3541_T2L
Q3612 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q3613 AE016772 T27T035410 FET 2SK3541_T2L
Q4204 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
Q4209 AE016772 T27T035410 FET 2SK3541_T2L
Q4210 AE016772 T27T035410 FET 2SK3541_T2L
Q4211 AE016772 T27T035410 FET 2SK3541_T2L
Q6201 AE013031 TPAAA05001 COMPOUND TRANSISTOR KRA101SRTK
Q6202 AE013010 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK
Q6203 AE013033 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK
Q6502 AE013011 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK
Q6504 AE013011 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK
Q7001 AE012951 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK
!
Q7002 AE012952 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)
!
Q7004 AE004664 TS3M000040 COMPOUND TRANSISTOR FW256-TL-E
K3-2 19LV61K
