Toshiba 24D343 DB User Manual

English - 48 -
English
Specications and Accessories
Broadcast Systems/Channels
DVB-T MPEG2, DVB-T MPEG4 HD
DVB-C MPEG2, DVB-C MPEG4
Video Input PAL, SECAM, NTSC 4.43
Stereo Nicam
External Connections
1-SCART 1 Input 21-pin SCART RGB, A/V
2-SCART-S (via SCART 1) Input 21-pin SCART S-Video
3-YPbPr (via VGA) Input Mini D-Sub 15-Pin Analogue
4-SIDE AV Input Side AV Cable input Video + Audio L + R
5-HDMI 1 Input Type A
6-PC Input Mini D-Sub 15-Pin Analogue RGB Signal
7-Digital Audio Output S/PDIF (Coaxial)
8-YPbPr Input YPbPr Connection Jack
USB Ports Media Browser Interface Version: USB 2.0
USB Class: Mass Storage
File System: FAT32
Headphone Socket 3.5mm stereo
Operating Conditions Temperature 5°C - 35°C (41°F - 94°F)
Humidity 20 - 80% (non-condensing)
Supplied Accessories Remote Control
2 batteries (AAA,IEC R03 1.5V)
Four screws
Side AV cable
YPbPr Connection Cable
Stand xing cover
P Clip
24” D
24” W
Energy Efciency Class
A A
Visible Screen Size (approx.)
61cm / 24” 61cm / 24”
On Mode Power Consumption (approx.) (*)
24 W 24W
Annual Power Consumption (approx.) (**)
35 kWh 35 kWh
Standby Power Consumption (approx.)
< 0.50 W < 0.50 W
Screen Resolution (pixels)
1366 x 768 1366 x 768
Display
16:9 16:9
Sound Output (at 10% distortion)
2 x 2.5 2 x 2.5
Power Consumption Model (approx.)
50 W 50W
Weight TV with stand
4.8 kg 4.4 kg
Gross weight
7.0 kg 6.5 kg
TV without stand
4.5 kg 3.6 kg
(*) Tested in accordance with IEC 62087-BD in default settings.
(**) Energy consumption 58 kWh per year, based on the power consumption of the television operating 4 hours per day for
365 days. The actual energy consumption will depend on how the television is used.
Specication is subject to change without notice.
A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm)
24D143*DB 567.1 348.9 162.6 57.7 386.9 75 75
24W143*DB 567.1 348.9 162.6 46.8 386.9 75 75
