47
HL57 (E/F) Web 213:276
Chapter 8: Appendix
Specifications
Notes:
• This model complies with the specifications listed
below.
• Designs and specifications are subject to change
without notice.
• This model may not be compatible with features and/or
specifications that may be added in the future.
Television System
NTSC standard
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source
120 V AC, 60 Hz
Power Consumption
26HL57: 80 W (average)
0.6 W in standby mode
32HL57: 95 W (average)
0.6 W in standby mode
37HL57: 123 W (average)
0.6 W in standby mode
42HL57: 157 W (average)
0.4 W in standby mode
Audio Power
10 W + 10 W
Speaker Type
2-3/8 × 4-3/4 inches (60 × 120 mm)
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohm or greater)
ColorStream
®
(component video) HD INPUT:
VIDEO:Y: 1V(p-p), 75 ohm
P
R: 0.7 V(p-p), 75 ohm
P
B: 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 720p, 480p, 480i
AUDIO: 150 mV(rms), 22 k ohm or greater
HDMI
™
INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID* compliant
Suggested formats: 1080p (24/60Hz), 1080i (60Hz),
720p (60Hz), 480p (60Hz), 480i (60Hz)
HDMI Audio: 2-channel PCM; 32/44.1/48 kHz
sampling frequency; 16/20/24 bits per sample
FIXED AUDIO OUTPUT:
150 mV(rms) (30% modulation equivalent, 2.2 k ohm
or less)
PC INPUT:
15-Pin D-sub Analog RGB
Dimensions
26HL57: Width: 26-1/4 inches (666 mm)
Height: 20-1/4 inches (514 mm)
Depth: 9-1/2 inches (241 mm)
32HL57: Width: 31-1/2 inches (800 mm)
Height: 23-3/8 inches (592 mm)
Depth: 11-1/4 inches (285 mm)
37HL57: Width: 36-1/4 inches (920 mm)
Height: 26-1/8 inches (661 mm)
Depth: 11-1/4 inches (285 mm)
42HL57: Width: 40-1/2 inches (1,027 mm)
Height: 28-5/8 inches (724 mm)
Depth: 13-1/4 inches (335 mm)
Mass (weight)
26HL57: 28.7 lbs (13.0 kg)
32HL57: 38.6 lbs (17.5 kg)
37HL57: 46.3 lbs (21.0 kg)
42HL57: 59.5 lbs (27.0 kg)
Operating conditions
Temperature: 32ºF - 95ºF (0ºC - 35ºC)
Humidity: 20 - 80% (no moisture condensation)
Supplied Accessories
• Remote control with two size “AAA” batteries
• Owner’s Manual (this book)
• Lead Clip–Use this clip to attach the TV to a wall, pillar,
or other immovable structure. See item 20 on page 3.
* E-EDID = Enhanced-Extended Display Identification
Pin No. Signal name Pin No. Signal name
1R 9NC
2 G 10 Ground
3B 11NC
4
NC
(Not connected)
12 NC
5NC 13H-sync
6 Ground 14 V-sync
7 Ground 15 NC
8 Ground
11C08.fm Page 47 Tuesday, March 20, 2007 3:18 PM
