Toshiba 48L545*DB User Manual

English - 52 -
English
Specications and Accessories
Broadcast Systems/Channels
DVB-T MPEG2, DVB-T MPEG4 HD, DVB-T2
DVB-C MPEG2, DVB-C MPEG4
Video Input PAL, SECAM, NTSC 4.43
Stereo Nicam
External Connections
1-SCART 1 Input 21-pin SCART RGB, A/V
2-SCART-S (via SCART 1) Input 21-pin SCART S-Video
3-SIDE AV Input Side AV Cable input Video + Audio L + R
4-HDMI Input Type A
5-PC Input Mini D-Sub 15-Pin Analogue RGB Signal
6-Digital Audio Output S/PDIF (Coaxial)
7-YPbPr Input YPbPr Connection Jack
8-LAN port RJ-45
USB Ports Media Browser Interface Version: USB 2.0
USB Class: Mass Storage
File System: FAT32
For sets with built in wireless unit
the Home network with a wireless
router must be compatible with; IEEE 80211 a/b/g/n
Security Protocols WEP 64/128, WPA, WPA2, TKIP, AES, WAPi.
Headphone Socket 3.5mm stereo
Operating Conditions Temperature 5°C - 35°C (41°F - 94°F)
Humidity 20 - 80% (non-condensing)
Supplied Accessories Remote Control
2 batteries (AAA,IEC R03 1.5V)
Four screws
Side AV cable
YPbPr Connection Cable
Stand xing cover
P Clip
Optional Accessories Active shutter 3D glasses – Toshiba FPT-AG04G and are available from the
retail outlet or Toshiba service company.
48” L
Energy Efciency Class A ++
Visible Screen Size (approx.) 121 cm / 48”
On Mode Power Consumption (approx.) (*) 44 W
Annual Power Consumption (approx.) (**) 64 kWh
Standby Power Consumption (approx.) < 0.50 W
Screen Resolution (pixels) 1920 x 1080
Display 16:9
Sound Output (at 10% distortion) 2 x 8
Power Consumption Model (approx.) 90 W
Weight TV with stand 18.5 kg
Gross weight 23.5 kg
TV without stand 15.5 kg
(*) Tested in accordance with IEC 62087-BD in default settings.
(**) Energy consumption 64 kWh per year, based on the power consumption of the television operating 4 hours per day for
365 days. The actual energy consumption will depend on how the television is used.
Unit Dimensions (Approximate)
Specication is subject to change without notice.
A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm)
48L545*DB 1092.2 643.5 250.1 105.4 697.7 400.0 400.0
