Toshiba E3 User Manual

16
8.2 I/O Point Map
NPT
1
NPA
2
Units Point Description Range / Value
AI 1 Hz Output frequency 0.00 ∼ 400.00
AI 2 % Output current 0 ∼ 255
AI 3 % Output voltage 0.0 ∼ 232.0
AI 4 % Input voltage 0.0 ∼ 255.0
AI 5 % IV terminal analog input value 0.00 ∼ 100.00
AI 6 % RR terminal analog input value 0.00 ∼ 100.00
AI 7 % RX terminal analog input value -100.00 ∼ 100.00
AI 8 kW Input power 0.0 ∼ 6553.4
AI 9 kW Output power -3276.8 ∼ 3276.7
AI 10 kWh System energy (KWh) 0 ∼ 999.9
AI 11 MWh System energy (MWh) 0 ∼ 65534
AI 12 -- Present fault 0 ∼ 82
AI 13 -- Past fault #1 (newest) 0 ∼ 82
AI 14 -- Past fault #2 0 ∼ 82
AI 15 -- Past fault #3 0 ∼ 82
AI 16 -- Past fault #4 (oldest) 0 ∼ 82
BI 1 -- Run / stop status 0=stopped
1=running
BI 2 -- Forward / reverse status 0=reverse
1=forward
BI 3 -- Acceleration/deceleration #1/#2
selection status
0=accel/decel #1
1=accel/decel #2
BI 4 -- Compulsory DC injection braking
mode status
0=inactive
1=active
BI 5 -- Coast stop command status 0=normal
1=coast to stop
BI 6 -- Emergency off status 0=normal
1=emergency off
BI 7 -- Fault status 0=EIII not faulted
1=EIII faulted
BI 8 -- Feedback control enable status 0=feedback invalid
1=feedback valid
BI 9 -- “F” input terminal status 0=terminal-CC open
1=terminal-CC shorted
BI 10 -- “R” input terminal status 0=terminal-CC open
1=terminal-CC shorted
BI 11 -- “S1” input terminal status 0=terminal-CC open
1=terminal-CC shorted
BI 12 -- “S2” input terminal status 0=terminal-CC open
1=terminal-CC shorted
BI 13 -- “S3” input terminal status 0=terminal-CC open
1=terminal-CC shorted
BI 14 -- “S4” input terminal status 0=terminal-CC open
1=terminal-CC shorted
