H-3
WAVEFORMS
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
POWER
48
49
STANDBY
5µs
5.0V
STANDBY
5µs
5.0V
SOUND AMP
50
1ms
50mV
CRT
45
POWER ON
20µs
5.0V
DEFLECTION
43
POWER ON
5ms
10.0V
44
POWER ON
20µs
5.0V
51
1ms
50mV
47
46
POWER ON
20µs
50V
POWER ON
20µs
50V
