2-6. Parts Layout in Outdoor Unit
NFC
NFC Low pressure sensor Accumulator TO sensor Check joint (Liquid pipe)
Check joint (Low pressure)
Check joint (High pressure)
High pressure sensor
NFC
8,10,12,14HP Model: MMY-MUP0801* MMY-MUP1001* MMY-MUP1201* MMY-MUP1401*
14A,16,18,20HP Model:
MMY-MUP14A1* MMY-MUP1601* MMY-MUP1801* MMY-MUP2001*
22,24HP Model: MMY-MUP2201* MMY-MUP2401*
Low pressure sensor Check joint (Low pressure) TO sensor Check joint (Liquid pipe)
Accumulator
High pressure sensor High pressure SW Check joint (High pressure) Compressor
High pressure SW Compressor
Low pressure sensor Accumulator TO sensor Check joint (Liquid pipe)
High pressure sensor High pressure SW1 High pressure SW2 Compressor 1
Compressor 2 Check joint
(High pressure)
Check joint (Low pressure)
- 24 -
