User’s Manual 3-17
Hardware, Utilities and Options
Figure 3-2 Inserting the ExpressCard (PORTÉGÉ A600)
5. After inserting the ExpressCard you should refer to its documentation
and also check the configuration in Windows in order to ensure that it is
correct.
Removing an ExpressCard
To remove an ExpressCard, follow the steps as detailed below.
1. Open the Safely Remove Hardware icon on the Windows Taskbar.
2. Point to ExpressCard and click the left Touch Pad control button.
3. Press the ExpressCard in order to eject the ExpressCard partially out of
the computer.
4. Grasp the ExpressCard and remove it.
Figure 3-3 Removing the ExpressCard (PORTÉGÉ R600)
ExpressCard
ExpressCard slot
ExpressCard
