The Grand Tour
Front with the display open
This section shows the computer with the display panel open. Lift the
display panel up to open the display and position it at a comfortable viewing
angle.
Figure 2-6 The front of the Touch Pad model with the display open
Wireless LAN antenna
(Non shown)
Web camera
Web camera LED
Display Screen
Stereo speaker tweeter
LCD Sensor
switch
Stereo speaker
Touchpad
Control buttons
Fingerprint
Sensor
Touchpad
Stereo speaker
Wireless LAN
antenna (Non
shown)
Microphone
Front operation panel
Power Button
UWB Antenna
(Non shown)
Mimo antenna (non shown)
System
indicators
Bluetooth
Antenna (Non
shown)
The speaker generates a magnetic field. Keep a magnetic card, such as a
credit card or bank card, away from the speakers.
