Toshiba RAS-10SA-E User Manual

– 7 –
2-2. Outdoor Unit
RAS-10SA-E
RAS-10SAX
600 85
36
111
ø25 Drain hole
50
30
216 230
8-ø6 Holes
(For fixing the outdoor unit)
4-ø11x14 Long holes
(For anchor bolt ø8-ø10)
Gas side (flare ø9.52)
Liquid side (flare ø6.35)
111
A
600
R10
50
36
25
216 230
ø11x14 Hole
ø6 Hole
Handle
11
525 530
5
268
Fan guard
ø420
TOSHIBA
770 59
89
200
11
12
Electric
parts cover
Z
54 62
Access for
charging
250
Z
View
600
45 or more
Inlet port
600 or more
(Minimum distance
of the wall)
4-ø11x14 Long holes
(For anchor bolt ø8-ø10)
200 or more
Outlet
port
Center
port
230
100 or more
Inlet port
Visible outline
of the product
A
Detail Drawing
Mounting dimension of anchor bolt
268
770
59
89
