60
CV510U (E/F) Web 213:276
Chapter 9: Appendix
Specifications
Note:
• This model complies with the specifications listed
below.
• Designs and specifications are subject to change
without notice.
• This model may not be compatible with features and/or
specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear,
unencrypted)
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source: 120 V AC, 60 Hz
Power Consumption
32CV510U: 1.3 Arms (maximum current)
0.4 W in standby mode
37CV510U: 1.6 Arms (maximum current)
0.4 W in standby mode
Audio Power: 9 W + 9 W
Speaker Type
Main: Two 1-3/8 × 6-3/8 inches (35 × 160 mm)
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 22 k
ohm or greater)
ColorStream
®
(component video) HD INPUT:
VIDEO:Y: 1V(p-p), 75 ohm
P
R: 0.7 V(p-p), 75 ohm
P
B: 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 720p, 480p, 480i
AUDIO: 150 mV(rms), 22 k ohm or greater
HDMI™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
Audio Lip Sync supported
Suggested formats: See table on the next page.
HDMI Audio: 2-channel Linear-PCM; 32/44.1/48 kHz
sampling frequency; 16/20/24 bits per sample
VARIABLE AUDIO OUTPUT:
0-300 mv (rms) (30% modulation equivalent, 2.2 k ohm
or less)
DIGITAL AUDIO OUTPUT:
Optical type
PC INPUT:
15-Pin D-sub Analog RGB
Dimensions
32CV510U: Width: 31 inches (786 mm)
Height: 22-3/8 inches (567 mm)
Depth: 9-3/4 inches (247 mm)
37CV510U: Width: 35-3/8 inches (902 mm)
Height: 25 inches (632 mm)
Depth: 9-3/4 inches (247 mm)
Mass (weight)
32CV510U: 30.6 lbs (13.9 kg)
37CV510U: 39.7 lbs (18.0 kg)
Operating conditions
Temperature: 32ºF - 95ºF (0ºC - 35ºC)
Humidity: 20 - 80% (no moisture condensation)
Supplied Accessories
• Remote control with two size “AAA” batteries
• Owner’s manual (this book)
• Securement Clip
Use this clip to attach the TV to a wall stud, pillar, or other
immovable structure. See item 20 on page 3 and
instructions on page 5.
• Cleaning cloth (to clean the cabinet and control panel)
32_37CV510U_EN.book Page 60 Friday, February 22, 2008 5:40 PM
