Thermostat Interface
Installation Manual
6-EN
1 Installation
 24V Thermostat Interface Installation and Orientation
Install the 24V Thermostat Interface on a flat surface using provided Wood Screws. Make sure that the installation result
complies with the local electrical code. The 24V Thermostat Interface is intended for indoor use only.
(1) Wall mount
Use the Wood Screws to attach the 24V Thermostat Interface. Do not install the 24V Thermostat Interface in a longitudinal
direction.
(2) Surface mount
Use the Wood Screws to attach the 24V Thermostat Interface.
Note: Make sure to comply with local codes and regulations.
Upper direction
Upper direction
