14
E6582171
■ Set motor parameters
Table 3-3. Motor parameters
The motor parameters require setting according to the motor used. For details, refer to the inverter instruction manual.
Title Function Name Parameter Setting Default Setting
F400 Offline auto-tuning
0: -
1: Reset motor parameters (0 after execution)
2: Auto-tuning at run command (0 after execution)
3: Auto-tuning at TB ON
4: Motor parameters auto calculation (0 after execution)
5: 4+2 (0 after execution)
6: Auto-tuning at run command during TB is ON
7: Auto-tuning F402 only at run command during TB is
ON
0
F401 Slip frequency gain 0 – 250% 70
F405
Motor rated capacity
(motor name plate)
0.10 – 315.0kW
Depends
on type.
F415
Motor rated current
(motor name plate)
Depend on capacity
F417
Motor rated speed
(motor name plate)
100 – 64000min
-1
F402 Automatic torque boost 0.01 – 30.00%
F416 Motor no load current 10 – 90%
F412 Leakage inductance 0.0 – 25.0%
