Unified Controller Vm series Controller typeS / typeL Virtualization Functional Manual
3
1.2 Supported OS
Supported guest OS as are as follows.
Table 1.1 Supported Model
Product type
Edition
Version
OS Build
KPUB21**S
Windows 10 IoT Enterprise LTSB 2016
32-bit
1607
14393
KPUB21*1S
Windows 10 IoT Enterprise LTSC 2019
64-bit
1809
17763
KPUB21A2S
Windows 10 IoT Enterprise LTSC 2021
64-bit
21H2
19044
◇
Remark
"IoT" is not displayed when Windows edition is displayed.
This is a Windows specification, and the Windows license is as shown in the table above.
◇
Remark
Event ID: 10016 is registered in the event viewer. We recommend that you ignore it because it
does not adversely affect the function, similar to Microsoft's view and recommendation.
1.3 Network Configuration
This section describes the network configuration of PLC / DCS.
Physical port EN-A and EN-B are shared by PLC / DCS and Windows. Set PLC’s / DCS’s
and Windows’ IP addresses to be assigned to the same physical port to different host
addresses within the same network address.
Table 1.2 An example of PLC Network Configuration
PUB21
display
nV-Tool
display
IP address
(PLC)
MAC address
(PLC)
IP address
(Windows)
MAC address
(Windows)
EN-A
LAN20
192.168.0.1
B8-6B-23-70-1B-E7
192.168.0.2
BA-6B-23-70-1B-E7
EN-B
LAN21
172.16.64.1.
B8-6B-23-71-1B-E7
172.16.64.2.
BA-6B-23-71-1B-E7
◆
Note
The G / L bit (normally 0) of the first half part (OUI) of the MAC address of the network card is
set to 1 on Windows. That is, the G / L bit in PLC and Windows is as follows.
0：PLC
1：Windows
◆
Note
In the case of B side PUB21 of the multi base unit, the nV-Tool display of LAN20 and LAN21
becomes LAN30 and LAN31 each.
