Toyota 7HBW23 Lift Truck Programming
Quick Reference Guide
Page 4 of 8
SOFTWARE / HARDWARE VERSIONS:
Enter the Special Truck Mode as before.
Continue to hold the horn button until Pn appears on the display then release the
horn.
Then, as before, scroll with the thumb lever to view the following:
• HPn = Hardware Part Number
• HSn= Hardware Serial Number
Then, simply end this section by pressing the red OFF button on the keypad.
ADDITIONAL INFORMATION:
In addition to the material covered, the 7HBW23 has many additional items to display
such as:
• Battery voltage at the ETAC
• Motor armature and field current
• Inputs from various switches
• Refer to the 7HBW23 Service Manual for additional information
