TP-Link Archer C20 User Manual

Archer C20
AC750 Wireless Dual Band Router
- 118 -

Note:
The current configuration will be covered with the uploading configuration file. Wrong process will
lead the device unmanaged. The restoring process lasts for 20 seconds and the router will restart
automatically then. Keep the power of the router on during the process, in case of any damage.
4.21.6 Reboot
Choose menu “System Tools
→
Reboot”, and then you can click the Reboot button to reboot
the router via the next screen.
Figure 4-116 Reboot the router
Some settings of the router will take effect only after rebooting, which include
• Change the LAN IP Address (system will reboot automatically).
• Upgrade the firmware of the router (system will reboot automatically).
• Restore the router's settings to factory defaults (system will reboot automatically).
• Update the configuration with the file (system will reboot automatically).
4.21.7 Password
Choose menu “System Tools
→
Password”, and then you can change the factory default user
name and password of the router in the next screen as shown in Figure 4-117.
Figure 4-117 Password
It is strongly recommended that you should change the factory default user name and password
of the router, because all users who try to access the router's Web-based utility or Quick Setup
will be prompted for the router's default user name and password.

TP-Link Archer C20 Specifications

General

Color	blue/white, blue
Wi-Fi Speed	0.733 gigabits per second
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
QoS Traffic Prioritization	yes
Ethernet Standard	10/100
Ethernet Switch	yes
Wireless Networking Standard	wi-fi 5
Wireless Standard	ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Antennas	3
Firewall	spi
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa-psk, wpa2-psk
Ports	rj-45
LAN Ports	4
WAN Ports	1
Built In Modem	no

Weight and Dimensions

Height	1.4 inches
Width	9.1 inches
