TP-Link M7350 User Manual

M7350
LTE-Advanced Mobile WiFi User Guide
-52-
Appendix C: Specifications
General
Standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Type
4G:FDD-LTE
3G: DC-HSPA+/HSPA/UMTS 2G: EDGE/GRPS/GSM
Certification CE, RoHS
Dimension 4.2 × 2.6 × 0.6 in. (106 × 66 × 16mm)
Interface
One Micro USB port, One SIM card slot, One Micro SD Memory card
slot
Button Power On/Off Button, RESET button, MENU button
Screen Display
/ Indicates the current network option: 4G/3G/2G, and signal
strength of current network.
Indicates the successful network connection.
Indicates you are in roaming service.
Displays the Wi-Fi status and the amount of current wireless
clients.
Indicates that there is un-read short message(s) and the amount
of un-read messages.
Displays the remaining battery power.
Indicates the download speed of current data transmission.
Indicates the upload speed of current data transmission.
Indicates the data used in total.
Power Supply
2550mAh Rechargeable Li-ion Battery
5VDC/1.0A External Power Adapter
Wireless
Band
FDD-LTE: 800/900/1800/2100/2600
Mhz
WCDMA: 900/2100Mhz
GSM: 850/900/1800/1900Mhz
Data Rate
Download: 150Mbps
Upload: 50Mbps
Frequency
2.4-2.4835GHz，5.15-5.25GHz，5.725-5.825GHz
EIRP <20dBm
Security WPA-PSK/WPA2-PSK
Antenna Internal Antenna
Environment
Temperature
Operating : 0℃~35℃
Storage: -20℃~60℃
Humidity
Operating: 10% ~ 90% RH, Non-condensing
Storage: 5% ~ 90% RH, Non-condensing

TP-Link M7350 Specifications

General

DHCP client	Yes
Ethernet LAN	No
Ethernet LAN (RJ-45) ports	-
Wi-Fi frequency	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rates supported	150 Mbit/s
Data network	2G, 3G, 4G, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
GSM bands supported	850, 900, 1800, 1900 MHz
UMTS bands supported	900, 2100 MHz
Device type	Cellular wireless network equipment
Certification	CE, RoHS
Product color	Black
Compatible memory cards	MicroSD (TransFlash)
Security algorithms	WPA-PSK, WPA2-PSK
Battery capacity	2000 mAh
Power source type	Battery
4G standard	LTE-FDD
2G standards	GPRS, GSM
3G standards	DC-HSPA+, HSPA, UMTS
SIM card type	MicroSIM
4G bands supported	800, 900, 1800, 2100, 2600 MHz
Number of simultaneous SIM cards	1
Market positioning	Portable
Mac operating systems supported	macOS
Mobile operating systems supported	Android, iOS
Windows operating systems supported	Windows 10, Windows 8, Windows 8.1, Windows Vista, Windows XP
Maximum memory card size	32 GB
Antenna type	Internal
Package depth	95 mm
Package width	135 mm
Package height	50 mm
Package weight	200 g
Cables included	Micro-USB
Harmonized System (HS) code	85176990
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	66 mm
Width	106 mm
Height	16 mm
Weight	- g
