TP-Link MC200CM User Manual

10
POWER LED lit on. Then you can operate it as the boxlike Media
Converter of the MC series.
5. Troubleshooting
If you encounter some problems when you install or use this product,
please try to solve the problem according to the following steps. If it still
doesn’t work, please contact your dealer or ask for help from our
technical support.
1. PWR LED is off: The power error. Please check that whether the
power lead is connected correctly or not.
2. LINK LED (TP port) is off: Please confirm that there is no open
circuit with cable and make sure that the connection type of the
device is 1000M.
3. LINK LED (FX port) is off:
1) Check the fiber mode and fiber type to make sure that they
match the Gigabit transceivers.
2) Check out that whether there is an open circuit or not.
3) Check the fiber loss by the Fiber-Optic Tester to avoid the
excess wastage of the fiber.
4) Make sure that the FX port is connected correctly as following:
The transmitting port (TX) of local end is connected to the
receiving port (RX) of outlying end. And the receiving port (RX)
of local end is connected to the transmitting port (TX) of
outlying end.

TP-Link MC200CM Specifications

General

DC-in jack	Yes
Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	850 nm
Fiber mode structure	Multi-mode
Maximum transfer distance	550 m
Fiber cable diameters supported (core/cladding)	50/125, 62.5/125 µm
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Link
Networking standards	IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Power consumption (max)	5.5 W
Sustainability certificates	RoHS
Package depth	165 mm
Package width	204 mm
Package height	65 mm
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
