TP-Link Tapo C110 User Manual

Authentication
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio interference, in which case the
user may be required to take adequate measures.
OPERATING FREQUENCY (the maximum transmitted power)
2412MHz–2472MHz (20dBm)
EU Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU, and (EU)2015/863. The original EU declaration
of conformity may be found at https://www.tp-link.com/en/ce
RF Exposure Information
This device meets the EU requirements (2014/53/EU Article 3.1a) on the limitation of exposure of the general
public to electromagnetic fields by way of health protection. The device complies with RF specifications when the
device used at 20 cm from your body. Restricted to indoor use.

TP-Link Tapo C110 Specifications

General

Type	IP security camera
Certification	FCC, IC, CE, NCC
Placement supported	Indoor
Connectivity technology	Wireless
Built-in HDD	No
DC-in jack	Yes
Form factor	Cube
Mounting type	Desk
Product color	White, Black
LED indicators	System
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of lenses	1
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	9.144 m
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264
Supported graphics resolutions	1920 x 1080 (HD 1080)
Audio system	2-way
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Sensor type	-
Optical sensor size	1/3.2 \
AC input voltage	100 - 240 V
DC output current	0.6 A
DC output voltage	9
Power consumption	300 mA
Power source type	AC, DC
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85258900

Weight and Dimensions

Depth	54.8 mm
Width	67.6 mm
Height	98.9 mm
