TD-8817 ADSL2+ Ethernet/USB Modem Router User Guide
26
MLD Proxy: The MLD (Multicast Listener Discovery Protocol) Proxy function is disabled by
default. If you want to enable the function, please click Enable.
Dual Stack Lite: Enable the Dual Stack Lite (D-S Lite) function if you need. It is disabled by
default.
4. Bridge Mode
If you select this type of connection, the modem router can be configured to act as a bridging
device between your LAN and your ISP. Bridges are devices that enable two or more networks to
communicate as if they are two segments of the same physical LAN.
Dual Stack Lite: Enable the Dual Stack Lite (D-S Lite) function if you need. It is disabled by
default.
Figure 4-14
Note:
After you finish the Internet configuration, please click SAVE to make the settings take effect.
4.3.1.3. IPv4/IPv6
If
you select IPv4/IPv6 as IP version, please follow both the 4.3.1.1 IPv4
and 4.3.1.2 IPv6
configuration based on different connection types to configure the parameters for WAN ports.
4.3.2 LAN
Choose “Interface Setup→LAN” menu, and you will see the LAN screen (shown in Figure 4-15).
Please configure the parameters for LAN ports according to the descriptions below.
