Appendix A: Specifications
General
Standards IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
Topology Star
Protocol CSMA/CD
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex)
Data Transfer Rate
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex)
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media(Cable)
100Base-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Number of Ports 5/8/16 10/100Mbps Auto-Negotiation RJ45 ports
LED indicators Power, 10/100Mbps Link/Act
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
10Base-T: 14880pps/Port
Frame Filter Rate
100Base-Tx: 148800pps/Port
10Base-T: 14880pps/Port
Frame Forward Rate
100Base-Tx: 148800pps/Port
Environmental and Physical
Operating Temperature
0℃ ~40℃ (32℉~104℉ )
Storage Temperature
-40℃ ~70℃ (-40℉ ~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing

TP-Link TL-SF1005D Specifications

General

MAC address table	1000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Networking standards	IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	100BASE-TX, 10BASE-T
Switch type	Unmanaged
Switch layer	-
Supported network protocols	CSMA/CD, TCP/IP
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	5
Certification	FCC, CE, RoHS
Product color	White
Heat dissipation	6.38 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power source	DC
Input current	0.6 A
Input voltage	5 V
Power consumption (max)	1.48 W
Package depth	91 mm
Package width	108 mm
Package height	85 mm
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	69.5 mm
Width	103.5 mm
Height	22 mm
