TP-Link TL-SF1008P User Manual

4
Chapter 2. Installation
During the installation procedure, please only use the
accessories equipped with the Switch.
2.1 Mounting the Switch on a Desk
To install the Switch, please follow the steps:
1) Place the Switch on a flat desk.
2) Remove the adhesive backing papers from the rubber
cushions.
3) Turnover the Switch and attach the supplied four rubber
cushions to the recessed areas on the bottom at each
corner of the Switch.
Note
1) Please avoid any heavy thing placed on the Switch.
2) Make sure the power is off before unplugging the power
adapter.

TP-Link TL-SF1008P Specifications

General

Heat dissipation	248.93 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
User guide	Yes
Package type	Box
Package depth	280 mm
Package width	223 mm
Package height	68 mm
Package weight	970 g
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	10GBASE-T, 100BASE-TX
Forwarding rate	1.1904 Mpps
MAC address table	2000 entries
Total Power over Ethernet (PoE) budget	57 W
Power over Ethernet plus (PoE+) ports quantity	8
Switch type	Unmanaged
Product color	Black
Housing material	Metal
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Power source	DC/PoE
Input current	1.31 A
AC input voltage	220 V
DC input voltage	53.5 V
AC input frequency	50 Hz
Power consumption (max)	66 W
Harmonized System (HS) code	85176990
IPv4 & IPv6 features	IPv6 portal
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	98 mm
Width	171 mm
Height	27 mm
